PLUS · Drilling
c6ex PLUS Drill Bit for Accessories & Consumables - Accessories & Consumables
PLUS-grade solution. Tuned for Accessories & Consumables
- Material
- Diamond
PLUS-grade solution
Tuned for Accessories & Consumables
Multi-source domestic supply
Why this series
Key benefits
PLUS-grade solution
PLUS-grade solution
Tuned for Accessories & Consumables
Tuned for Accessories & Consumables
Multi-source domestic supply
Multi-source domestic supply
SKU table
Series specifications
Orderable SKUs with key geometry and dimensions. Send the SKU(s) you need for a quote.
| c6ex SKU | Part No. | Description |
|---|---|---|
| C6EX-DR-GN-0488 | 100669 | AW Rod Pin to BWL Rod Pin |
| C6EX-DR-GN-0489 | 100671 | NW Rod Pin to BWL Rod Pin |
| C6EX-DR-GN-0490 | 102571 | NW Rod Pin to BWL Bullnose |
| C6EX-DR-GN-0491 | 100667 | AW Rod Pin to NWL Rod Pin |
| C6EX-DR-GN-0492 | 100852 | AW Rod Pin to ND Rod Pin |
| C6EX-DR-GN-0493 | 100595 | NW Rod Pin to NWL Rod Pin |
| C6EX-DR-GN-0494 | 102589 | NW Rod Pin to ND Rod Pin |
| C6EX-DR-GN-0495 | 102590 | NW Rod Pin to NWL Bullnose |
| C6EX-DR-GN-0496 | 102591 | NW Rod Pin to ND Bullnose |
| C6EX-DR-GN-0497 | 106002 | AW Rod Pin to NS Rod Pin |
| C6EX-DR-GN-0498 | 106130 | NW Rod Pin to NS Pin |
| C6EX-DR-GN-0499 | 106138 | NW Rod Pin to NS Bullnose |
| C6EX-DR-GN-0500 | 100596 | NW Rod Pin to HWL Rod Pin |
| C6EX-DR-GN-0501 | 102612 | NW Rod Pin to HD Rod Pin |
| C6EX-DR-GN-0502 | 102613 | NW Rod Pin to HWL Bullnose |
| C6EX-DR-GN-0503 | 102614 | NW Rod Pin to HD Bullnose |
| C6EX-DR-GN-0504 | 102633 | NW Rod Pin to PD Rod (HWT Casing) Pin |
| C6EX-DR-GN-0505 | 102634 | NW Rod Pin to PD Rod (HWT Casing) Bullnose |
| C6EX-DR-GN-0506 | 101104 | Gauge Assembly, Bit & Shell |
| C6EX-DR-GN-0507 | 101112 | Gauge, Max New Shell |
| C6EX-DR-GN-0508 | 101113 | Gauge, Min New Shell |
| C6EX-DR-GN-0509 | 101114 | Gauge, Max New Bit / Worn Shell |
| C6EX-DR-GN-0510 | 101115 | Gauge, Min New Bit |
| C6EX-DR-GN-0511 | 101128 | Hex Bolt, 1/4-20 UNC x 2″ Long, Zinc Plated |
| C6EX-DR-GN-0512 | 101129 | Washer, 17/64″ ID x 1/2″ OD, Zinc Plated |
| C6EX-DR-GN-0513 | 101130 | Nylock Nit, 1/4-20 UNC, Zinc Plated |
| C6EX-DR-GN-0514 | 101105 | Gauge Assembly, Bit & Shell |
| C6EX-DR-GN-0515 | 101116 | Gauge, Max New Shell |
| C6EX-DR-GN-0516 | 101117 | Gauge, Min New Shell |
| C6EX-DR-GN-0517 | 101118 | Gauge, Max New Bit / Worn Shell |
| C6EX-DR-GN-0518 | 101119 | Gauge, Min New Bit |
| C6EX-DR-GN-0519 | 101106 | Gauge Assembly, Bit & Shell |
| C6EX-DR-GN-0520 | 101120 | Gauge, Max New Shell |
| C6EX-DR-GN-0521 | 101121 | Gauge, Min New Shell |
| C6EX-DR-GN-0522 | 101122 | Gauge, Max New Bit / Worn Shell |
| C6EX-DR-GN-0523 | 101123 | Gauge, Min New Bit |
| C6EX-DR-GN-0524 | 102286 | OD Gauge Assembly |
| C6EX-DR-GN-0525 | 102396 | OD Gauge, Drill Rod New |
| C6EX-DR-GN-0526 | 102398 | OD Gauge, Drill Rod Wear |
| C6EX-DR-GN-0527 | 101084 | Lock Nut, OD Gauge |
| C6EX-DR-GN-0528 | 101083 | Flat Washer, OD Gauge |
| C6EX-DR-GN-0529 | 101082 | Hex Bolt, OD Gauge |
| C6EX-DR-GN-0530 | 102400 | Wear Sample |
| C6EX-DR-GN-0531 | 101087 | OD Gauge Assembly |
| C6EX-DR-GN-0532 | 101085 | OD Gauge, Drill Rod New |
| C6EX-DR-GN-0533 | 101057 | OD Gauge, Drill Rod Wear |
| C6EX-DR-GN-0534 | 101090 | Wear Sample |
| C6EX-DR-GN-0535 | 101088 | OD Gauge Assembly |
| C6EX-DR-GN-0536 | 101086 | OD Gauge, Drill Rod New |
| C6EX-DR-GN-0537 | 101058 | OD Gauge, Drill Rod Wear |
| C6EX-DR-GN-0538 | 101091 | Wear Sample |
Series specs
Specification snapshot
Material, bond, and process fit for selection and sampling.
| Material | Diamond |
|---|---|
| Operations | Core Drilling |
Application fit
Primary application
The primary application this series is engineered for.
Quote context
Send your workpiece, machine, and cycle target — we engineer the tool.
Route an inquiry for c6ex PLUS Drill Bit for Accessories & Consumables - Accessories & Consumables with your material, parameters, and volume. No price listing; each series is quoted to your application.
